Wiring Connecting Terminals - HTB-1100S Single Mode Fiber Optic transceivers Media Converter with Power Adapter

Description

HTB-1100S single mode fiber optic transceivers Media Converter with power adapter
Feature
Auto negotiation function allows UTP port to select the transmission mode of 10/100M and Full Duplex or Half Duplex.
UTP port supports MDI/MDI-X auto crossover.
Optical interface chosen: SC multimode
Supporting 1552 Byte packet
Internal circuit of prevented thunder could greatly reduce damage of the converter caused by thunderbolt induction.
specification
Fiber Type: single-mode
Condition: New in Box - Includes Power Cord and Manual
Operating standards: IEEE802.3u, 10/100Base-TX and 100Base-FX
MAC address table: 1K
Connector:
UTP: RJ-45 10/100Mbps.
Fiber: SC 100Mbps
Cable:
UTP: Cat. 5 UTP (the max distance up to 100m)
Fiber (single mode): 50/125, 62.5/125 m(the max distance up to 2km or 5km)
Flow Control
Full Duplex: Supporting standard IEEE802.3x
Half Duplex: Backpressure
LED: Power, FX FDX, FX Link/Act, TX 100, TX FDX, TX Link/Act.
Power: AC 110V-240V to DC 5V. DC 48V to DC 5V.
Ambient Temperature: 0 ~ 70 degree
Humidity: 5% ~ 90%
Dimensions:
Internal power: 30 110 140mm
External power: 26 70 93mm
package including
HTB-1100S Fiber Media Converter 1 pc
Power Cord 1pc
user manual 1pc
Post/Royal Mail/Swiss Post//////,etc.
* by /// is about to most countries.
takes about . HK post takes about to most
countries. takes tofull territory in US. Royal Mail takes around
to full territory in UK. Swi
