Smiley Antenna Co., Inc 465 mhz Super Stick IV Telescoping Antenna (MX)

Description

• SUPER STICK IV 5/8 wave flexible base loaded telescopic antenna is the standard for field use whether in the countryside or city.
• This super efficient UHF antenna provides a OMNI directional 6 to 9 db gain and is usable in 2 positions. Fully extended or fully collapsed. It is a true 1/4 wave when collapsed & 5/8 wave when extended
• Modular construction features replaceable telescopic section, tuned coil/spring & available with any TA Base. This flex coil matching network provides at band center low SWR as well as a 5 MHz band center.
• SUPER STICK IV 5/8 wave flexible base loaded telescopic antenna is the standard for field use whether in the countryside or city. This super efficient UHF antenna provides a OMNI directional 6 to 9 db gain and is usable in 2 positions. Fully extended or fully collapsed. It is a true 1/4 wave when collapsed & 5/8 wave when extended.
• Electrical - 50 Watts max power, Impedance matched to the portable
• Helical Elements Construction, Exterior exclusive NT-mil covering - Dipped in synthetic rubber to provide a weather seal & webb coil, preventing distortion, Telescopic section & highly efficient copper-plated helical wound hardened steel wire, Flow soldered nickel plated brass base
• In addition, you should note that they use a modular system, and that the antenna can be furnished with any of a multitude of Smiley Antenna connectors.
• The tuned antenna bases are all flow soldered assuring excelled electrical connection, plus double protection at point of maximum stress. The Smiley Antenna Company has universal bases that fit most radios; the bases are nickel plated brass (not steel), preventing dissimilar metal oxidation or rust. Our Antenna can be fitted to over 10 different connectors, such as BNC, TNC, and SMA. At Smiley Antenna Company, we manufacturer our own bases.

SUPER STICK IV 5/8 wave flexible base loaded telescopic antenna is the standard for field use whether in the countryside or city. This super efficient UHF antenna provides a OMNI directional 6 to 9 db gain and is usable in 2 positions. Fully extended or fully collapsed. It is a true 1/4 wave when collapsed & 5/8 wave when extended. Modular construction features replaceable telescopic section, tuned coil/spring & available with any TA Base. This flex coil matching network provides at band center low SWR as well as a 5 MHz band center. Antenna tuned at 465 MHz being the band center, the antenna will perform the same between 460 - 470 MHz. Length Telescope 10" down and 48" up. *Base fits Baofeng, Wouxon, Yaesu, Icom, Kenwood, Uniden, Radioddity, Btech, and More ( **See Radio Manual for Proper Base Selection for Antenna)
